ALLMTN CF 6

ALLMTN CF 6

£4,499.99

ABOUT THE BIKE

Are you looking for an electric full-suspension bike with which you can master steep uphills just as smoothly as demanding downhills? Then the AllTrail 5 27.5 is your perfect companion for any terrain: The Yamaha PW-ST drive with an integrated 630 Wh battery provides reliable and powerful support. 140 mm suspension travel at the front and 150 mm at the rear, 4-piston disc brakes, and 27.5″ wheels with Plus tyres offer you riding fun and safety in every situation.



Clear
SKU: N/A Categories: , , ,

Description

ABOUT THE BIKE

Are you looking for a sporty e-Fully with high-quality components for lots of fun on the trail? Then the new Haibike AllMtn CF 6 should be your choice! With its lightweight all-carbon frame, powerful Yamaha PW-X2 motor and 600 Wh battery as well as a progressive geometry, this e-MTB offers you pure and uncompromising trail e-performance. The SRAM GX Eagle rear derailleur, the RockShox Yari air suspension fork and hydraulic disc brakes ensure that you are well prepared for even demanding terrain and can plunge from one e-mountain bike adventure into the next.

KEY FEATURES

  • Frame material

    FRAME MATERIAL

    Full Carbon

  • Drive unit

    DRIVE UNIT

    Yamaha PW-X2, 80Nm, 25km/h

  • Battery

    BATTERY

    Yamaha InTube 600Wh

  • Fork

    FORK

    RockShox Yari RC, Travel: 160mm

Specification

SPECIFICATIONS

    • ENGINE

      Yamaha, PW-ST System, 250 Wh, 70 Nm, 25 km/h

    • DISPLAY

      Yamaha, Side Switch, 1.7″ LCD, 7 functions

    • BATTERY

      Yamaha, InTube, 630 Wh

    • FRAME FAMILY

      Haibike, FullSeven Yamaha i630, Aluminium 6061

    • FORK

      RockShox, 35 Silver, Steel spring, 140 mm travel, Aluminium steerer tube 1 1/8″ – 1 1/2″ tapered, 15 x 110mm thru-axle Boost

    • DAMPER

      RockShox, Deluxe Select, Air, Trunnion Mount

    • CRANK ARM

      Haibike Components, The Crank +, Aluminium

    • BRAKE (FRONT)

      Tektro, Orion M745, 4-piston disc brake

    • BRAKE (REAR)

      Tektro, Orion M745, 4-piston disc brake

    • TUBE

      Presta valve

    • RIM

      Rodi, Tryp 30, With Eyelets, Double Wall, Aluminium

    • CLAMPING RING

      Internal hexagon, 34.9 mm

    • REAR DERAILLEUR

      Shimano, Deore M6100

    • SHIFT LEVER

      Shimano, Deore M6100, Trigger switch

    • BOTTOM BRACKET

      integrated in the motor

    • SPROCKET

      Shimano, M6100, 10 – 51 teeth

    • CHAIN

      Shimano, CN-M6100

    • CHAINRING

      Steel, 38 teeth

    • CHAIN GUIDE

      Nylon directmount

    • BRAKE LEVER

      Tektro, Orion M745, Aluminium

    • BRAKE DISC (FRONT)

      Tektro, TR203, 203 mm

    • BRAKE DISC (REAR)

      Tektro, TR180, 180 mm

    • TYRE

      Schwalbe, Nobby Nic Performance, 65-584, 27.5 x 2.6 inch

    • FRONT WHEEL HUB

      Haibike Components, TheHub ++, 6-bolt standard

    • REAR WHEEL HUB

      Haibike Components, TheHub ++, 6-bolt standard

    • SPOKES

      Sapim, Leader

    • HANDLEBAR

      Haibike Components, TheBar ++, 780 mm

    • GRIPS

      Haibike, MTB grips

    • STEM

      Haibike Components, TheStem ++, A-head, 31.8 mm, 7.0 degrees

    • HEADSET

      Feimin, A-Head Tapered, Ball bearing

    • SADDLE

      Selle Bassano, Reko R2 E-Sport

    • SEAT POST

      Dropper-Post Remote 31.6, Aluminium, Telescope, 31.6 mm

    • PEDALS

      Freeridepedal, Aluminium, with Reflector

    • PERMITTED TOTAL WEIGHT

      120.0 kg

GEOMETRY

FRAME SIZE (I.E. S, M, …)SML
AFRAME HEIGHT (CM)40.0 cm44.0 cm48.0 cm
BSEAT TUBE ANGLE73.0 degrees73.0 degrees73.0 degrees
DSEAT ANGLE73.0 degrees73.0 degrees73.0 degrees
EHEAD TUBE LENGTH140.0 mm125.0 mm130.0 mm
FHEAD TUBE ANGLE (DEGREES)67.0 degrees67.0 degrees67.0 degrees
GTOP TUBE HORIZONTAL590.0 mm600.0 mm620.0 mm
HCHAIN STAY LENGTH470.0 mm470.0 mm470.0 mm
IBOTTOM BRACKET DROP0.0 mm0.0 mm0.0 mm
JWHEELBASE1180.0 mm1188.0 mm1208.0 mm
KSTACK614.0 mm600.0 mm605.0 mm
LREACH402.0 mm417.0 mm435.0 mm
